1uzfe sumps

[ash]

hi,
can anyone tell me what sump this is?
is it MID , or REAR



[devojet]

Looks like a MID.



[XR8tt]

It's NOT front..
Here's a pic of modified front upper pan..



[ash]

yeep, ok ta

how far back does the rear sump mount, if the housing i got is a mid ?



[BlackUZZ31]

landcruiser looks about the most rear you can get but the pan looks funky

http://www.toyodiy.com/parts/p_J_199901_TOYOTA_LAND+CRUISER_UZJ100W-GNPZK_1105.2.html?hl=12101



[ash]

cool, thanks
it still allows room to fit the converter bolts in from the front.
looks like it will hold more oil too than the mid sumps, which is what i want



[ash]

i may have to modify these mid sumps, to increase oil ,and control it..
probaly put a hole or 2 in the sumps soon,... need the spares.



[ash]

thank you justin sir...


http://www.onsills.com/onsills08/php...hp?f=9&p=31416



[XR8tt]

http://www.lextreme.com/forums/showthread.php?t=13840&highlight=rear+sump

I added 80mm depth to my front sump.. Hope to help in oil control ...



[gloverman]

Here are photos of front, mid and rear passenger car sumps. They are pretty old photos now but still helpful. 2uz sumps are really good for the 4x4 stuff. I also have part of a 4x4 aristo sump. Hope these help. Cheers



[ash]

i wounder if the mid sump pickup will work with the rear sump ?
looks close

thanks for the pictures



[ash]

lol.. need the edit feature to fix my spelling...



[gloverman]

Mid sump pickups do not work with the rear sump Sorry. Close but not quite. Cheers



[ash]

Mid sump pickups do not work with the rear sump Sorry. Close but not quite. Cheers

cheer thanks
