Upper Inlet Manifold Cad File

PARTS FOR SALE: Limited availability on 1UZFE EGR Delete Kits, Torque Converters and Supercharger Fish Brackets. No turbo kits. Email for info: [email protected]

Alan Whitaker

Member
Messages
331
Location
Leeds
Hi All,
Don't know where I saw it but there was a cad file of the top flange for a 1UZ-FE flange, I am talking about the split from the lower an upper manifold (the one you would bolt a supercharger to)

Many Thanks

Alan


Alan Whitaker

Member
Messages
331
Location
Leeds
Hi
Not mounting a blower, I am looking at a turbo manifold, I know there was one on V-eight but the site is down (long term).
Just looking at a flange to build up from.

Alan


FoPar

New Member
Messages
413
Location
Sydney, Australia
try Bain Racing, thats exactly what we did


Alan Whitaker

Member
Messages
331
Location
Leeds
Hi All
Got a full set of cad drawings, bottom flange a top flange, lid and 4 small trumpet flanges, all for $20, not bad. will be at the cutters tuesday to get them cut in 6mm ally.
Pictures to follow

Alan


Alan Whitaker

Member
Messages
331
Location
Leeds
At the shop being cut, should pick it up next week with the lower flange, have 2 sets of Hayabusa 1000r5 throttle bodys so next weel should be able to look at this starting this project.

Alan
